Gaurang Din Rail Enclosure 110 * 70 * 48.55mm for Electronic Home Automation PLC Switch box industrial boxes electrical box ABS enclosure Din Rail Enclosure Control Box (CEB-70-02)
Original price was: ₹650.00.₹565.00Current price is: ₹565.00.
Price: ₹650 - ₹565.00
(as of Mar 27, 2026 17:17:01 UTC – Details)
Product Description
Compact Enclosures
Compact Enclosures accommodate Base & Display PCB and open space for Euro Terminals and custom connectors. It has Din Rail & Wall mounting facility. It is ideal for Home automation, electronic Boards and Controls.
Compact Enclosures
CES-35 – 12 Terminals
35 MM Width12 ConnectionsBase PCBDisplay PCBDin Rail / Wall Mounting
CES-70 – 24 Terminals
70 MM Width24 ConnectionsBase PCBDisplay PCBDin Rail / Wall Mounting
CES-105 – 40 Terminals
105 MM Width40 ConnectionsBase PCBDin Rail / Wall Mounting
CES-157 – 56 Terminals
157 MM Width56 ConnectionsBase PCBDisplay PCBHorizontal PCBVertical PCBDin Rail / Wall Mounting
CEB-35 – 6 Terminals
35 MM Width6 ConnectionsBase PCBDisplay PCBDin Rail / Wall Mounting
CEB-70 – 12 Terminals
70 MM Width12 ConnectionsBase PCBDisplay PCBDin Rail / Wall Mounting
CEB-105 – 20 Terminals
105 MM Width20 ConnectionsBase PCBDin Rail / Wall Mounting
CEC-70
70 MM Width1 Base PCBDisplay PCBDin Rail / Wall Mounting
CEC-105
105 MM Width1 Base PCBDisplay PCBDin Rail / Wall Mounting
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Customer Reviews
—
2.0 out of 5 stars 1
4.4 out of 5 stars 2
2.9 out of 5 stars 2
5.0 out of 5 stars 1
—
Price
₹548.00₹548.00 ₹775.00₹775.00 ₹565.00₹565.00 ₹825.00₹825.00 ₹475.00₹475.00 ₹1,545.00₹1,545.00
Width
35 MM 70 MM 70 MM 105 MM 105 MM 157 MM
Connections
12 24 12 20 56
Base PCB
✓
✓
✓
✓
✓
✓
Display PCB
✓
✓
✓
no data
✓
✓
Horizontal PCB
no data
no data
no data
no data
no data
✓
Vertical PCBs
no data
no data
no data
no data
no data
✓
With Ventilation
✓
✓
✓
✓
✓
✓
Without Ventilation
✓
✓
✓
✓
✓
no data
Din Rail / Wall Mounting
✓
✓
✓
✓
✓
✓
Low Height Enclosure for Compact Instruments
Innovative Clips design facilitates Wall / Rail Mount to Enclosures by changing its position in Base plate.
For RASPBERRY PI – ARDUINO BEAGLEBONE – ODROID type Popular Embedded electronic boards
Dimensional size per DIN 43 880 – Can be mounted with Distribution system along with MCB
Snap-together design speeds up assembly.
Two PCBs provision – Base PCB fixed on Base Plate and Display PCB for which cover has screw mounting tabs.
It can accommodate Max. 12 Terminal – standard 5mm pitch fixed OR Plug-In type.
Protection – IP20 (finger protected) Protection against accidental contact.
Terminals are optional – Enclosure supplied with / without terminals – customer can use standard commercial terminal available of their choice.
Package Content: (1) CEB-70-01 Without Ventilation without Terminals & CEBV-70-01 With Ventilation without Terminals – 1 x Case Top cover, 1 x Base Plate, 2 x Mounting Clips, 2 x Screws (2) CEB-70-02 Without Ventilation with Terminals & CEBV-70-02 With Ventilation with Terminals – 1 x Case Top cover, 1 x Base Plate, 2 x Mounting Clips, 2 x Screws, 6 x 2way Euro Terminals (Total 12 Euro Terminals) – (Note: The item does not include PCB and DIN Rail.)
