Ultra Low Power 2.4Ghz Nrf24L01 Rf Wireless Transceiver In Antistatic Foam Wireless Transceiver Module

Price: ₹699 - ₹199.00
(as of Mar 28, 2026 01:25:03 UTC – Details)


The nRF24L01 is a single chip 2.4GHz transceiver with an embedded baseband protocol engine designed for ultra low power wireless applications.
The nRF24L01 is designed for operation in the world wide ISM frequency band at 2.400 – 2.4835GHz. An MCU (microcontroller) and very few external passive components are needed to design a radio system with the nRF24L01. The nRF24L01 is configured and operated through a Serial Peripheral Interface (SPI.) Through this interface the register map is available. The register map contains all configuration registers in the nRF24L01 and is accessible in all operation modes of the chip.
NRF24L01 is a universal ISM band monolithic transceiver chip works in the 2.4-2.5GHz
Wireless transceiver including: Frequency generator, enhanced type, mode controller, power amplifier, crystal amplifier, modulator, demodulator
Built-in 2.4GHz antenna, supports up to six channels of data reception Size: 15 x 29mm Low operating voltage: 1.9-3.6V
High Rate: 2Mbps, as air transmission time is very short, greatly reducing collision phenomena in wireless transmission (air transfer rate of software setting: 1Mbps or 2Mbps)
Low power consumption: When the answer mode communication, fast air transmission and start-up time, which greatly reduces the current consumption
